The SW-620-TX-W Conference Presentation Switcher features USB-C/HDMI input, as well as support for Miracast, Airplay and Wireless casting via APO-DG2/APO-DG2-PRO, allowing simple and clean installation.
Experience the full potential of USB-C with support for 4K video, USB 3.0 data transfer, and 100W charging. The SW-620-TX-W also supports dual video output via a single USB-C input cable, providing exceptional flexibility for multi-screen presentations.
The switcher offers multiple switching methods, including automatic switching and independent USB and video switching. This ensures that your presentation flows smoothly, with minimal manual intervention required.
Robust Connectivity and Control: Equipped with three USB 3.0 device ports, one balanced audio de-embedding port, RS232, and MUTE port, the SW-620-TX-W allows for seamless integration with various conference equipment. Additionally, the dual RJ-45 ports support Ethernet functionality in transparent mode, where it acts as a normal switch or isolated mode where control port is isolated.
Inputs
1x HDMI: 19-pin type A, up to 4K@30Hz 4:4:4 8bit1x USB-C, Video input with MST, up to 2x 4K@30HzWireless Video from APO-DG2, APO-DG2-PRO (1080@60Hz, 2160@30Hz), Airplay or Miracast source (1080@60Hz)
Outputs
2x HDMI: 19-pin type A, Output 1 – 4K@60Hz 4:4:4 8bit, Output 2 – 4K@30Hz 4:4:4 8bit,1x Analog Audio Output (5-pin Phoenix Male Connector)
Audio Formats
2ch PCM
Output Video Encoding
HDMI
Supported Standards
DCI | RGB
Maximum Pixel Clock
300MHz (600MHz on HDMI OUT1)
COMMUNICATION AND CONTROL
HDMI CEC | HDCP 2.3 | EDID
USB
3 x USB 3.0 Type A device ports | 5v 1000mA per port1 x USB 3.0 Type B host port (assignable)1 x USB 3.0 Type-C port
RS-232
1x 4-pin Phoenix (API control) | Provides 12v power
LAN
2x 8-pin RJ-45 for API control (Telnet, TLS, HTTP/HTTPS for webUI)
Wireless
4x Wi-Fi Antennas | IEEE 802.11 a/b/g/n/ac | Dual-band 2.4 & 5GHz | WEP, TKIP, AES, WPA, WPA2Max E.I.R.P. :16.38 dBm (43.45mW)
WiFi Operation Frequency:2.4G: 2412MHz~2462MHz5G: 5180MHz~5240MHz5.8G: 5745MHz~5805MHz
Maximum Power:14.89 dBm (E.I.R.P.)16.38 dBm (E.I.R.P.)10.81 dBm (E.I.R.P.)
POWER
Power Supply
20V 10A
Max Power Consumption
132W
