The CAM-0402-BRG is a compact and powerful 4K multi-camera video bridge designed to simplify video switching and integration for conferencing, streaming, recording, and hybrid events. Supporting up to four wired inputs (2x HDMI, 2x USB), this device delivers a unified video output via USB or HDMI — all in stunning 4K resolution.
Whether you’re combining professional cameras or document cameras from across the network, the CAM-0402-BRG offers seamless multiview capabilities and flexible control options via Buttons, Web UI, API, or RS-232. It appears as a standard USB webcam (UVC/UAC), making it plug-and-play with all major conferencing and streaming platforms like Microsoft Teams, Zoom, OBS, and more.
Now with native integration into Microsoft Teams via the WyreStorm Teams app, users can control camera switching directly from within a meeting — no additional software or hardware required.
Perfect for corporate AV, education, live production, and government environments, CAM-0402-BRG brings professional-grade mixing into an easy-to-use form factor.
Seamlessly mix up to eight video sources from a variety of formats — including 2 HDMI inputs and 2 USB 3.0 UVC cameras. This versatility allows users to combine local and remote sources in a single workflow, making it ideal for hybrid meetings, training sessions, and multi-angle streaming productions.
The CAM-0402-BRG delivers a unified video output through USB (UVC) and HDMI simultaneously. Whether you need a clean single view or a multiview layout with up to four sources on-screen at once, this device offers maximum flexibility for streaming, local display, and remote contribution — all in up to 4K resolution.
Take control directly within your collaboration environment. With WyreStorm’s custom Microsoft Teams app, users can control source switching from inside a live Teams meeting — no need for a separate control interface or third-party system. This integration streamlines user experience in corporate and educational settings.
The USB HOST output appears as a standard UVC/UAC webcam, making it instantly recognized by any video conferencing or recording platform without additional drivers. Compatible with Zoom, Teams, Google Meet, OBS, vMix, and more — it’s the easiest way to bring multiple camera feeds into your workflow.
Inputs
2 x USB 3.0 Type-A (up to 3840×2160@30Hz MJPEG)2 x HDMI (up to 3840×2160@30Hz)
Outputs
1 x USB Type-C (up to 3840×2160@30Hz, MJPEG)1 x HDMI (up to 3840×2160@30Hz)
Multiview Support
HDMI out and USB HOST share the same signal and support multiview display (up to quad-view)
Control Options
RS-232, Web GUI, LAN
OS Compatibility
Windows 10 or abovemacOS 10.15 or above
USB Protocols
UVC & UAC
HDCP Compliance
HDCP 2.2
CEC Support
HDMI outputs support CEC one-touch play and standby (customizable via Web UI)
EDID Coniguration
Web UI and API adjustableDefault: 4K@30Hz stereo audio
Video Formats
HDMI: up to 4K@30HzUSB: MJPEG up to 4K@30Hz
Audio Formats
HDMI IN:RAW PCM, 16-bit, 2-channel, 32/44.1/48KHzUSB IN:RAW PCM, 16-bit, 2-channel, 16/32/48KHzHDMI OUT:RAW PCM, 16-bit, 2-channel, 48KHzUSB HOST: RAW PCM, 16-bit, 2-channel, 48KHz
Supported Standards
DCI | RGB
Maximum Pixel Clock (HDMI)
300MHz
POWER
Power Supply
DC 20V/3A via 5.5/2.1mm barrel connector
Power Consumption
36W
